System structure: | Embedded Linux system, ARM chip structure |
Chip | AK3918E |
Resolution: | 2.0MP |
Sensor Resolution: | 1/2.9"SC2232H、GC2063 1920*1080 |
Lens | Fisheye lens (1.35±3%mm) |
Lens view angle: | 360° |
View angle: | Horizontal: 185°/ Vertical:185° |
Video compression standard: | H.265/20FPS |
Minimum illumination: | 0.02Lux@（F2.0，VGC ON),O.Luxwith IR |
Electronic shutter: | Auto |
Backlight compensation: | Support |
Noise reduction: | 2D、3D |
Led quantity: | 3PCS infrared LED |
Network: | WIFI wireless transmission (support IEEE802.11b/g/n wireless protocol). |
Network connection: | WIFI, AP hotspot |
Night vision: | IR-CUT switch Automatic，about 5-8meters (It varies from environment) |
Audio | Built-in microphone and speaker, support real-time two-way audio transmission.ADPCM audio compression standard, self-adapt to code stream |
Network protocol: | TCP/IP、UDP、RTSP、HTTP DDNS、DHCP、FTP、NTP |
Alarm | 1.Motion detection and picture push 2.AI Human intrusion Detection(optional) |
ONVIF | Support ONVIF |
Storage: | TF Card（Max 128G）；Cloud storage /Cloud disk (optional) |
